JSV-6 Compact Simple Monoblock Progressive Divider Valves
JSV progressive divider valve is a compact, monolithic unit designed for efficient lubrication in tight spaces. These valves operate in sequence, ensuring even distribution of lubricant to all outlets. If one outlet becomes blocked, the entire system stops operating.
Description
Feature
Lubricant input: Lubricant enters the inlet of the distribution valve through the lubrication pump.
Sequential distribution: The pistons in the divider valve move in sequence to distribute the lubricant to each outlet. The movement of each piston pushes the next piston, forming a continuous cycle.
Even distribution: Each outlet distributes the same amount of lubricant in each cycle, ensuring that all lubrication points are evenly lubricated.
Fault detection: If an outlet is blocked, the entire system will stop running, which is convenient for detection and maintenance.
Specification
| Function principle | Metering devices |
| Numbers of Outlets | 6-20 |
| Metering quantity | 0.2mL/cycle |
| Lubricant | Grease up to NLGI 2, oil 32-220cSt@40℃ |
| Operating temperature | –20 to +80 °C |
| Operating pressure | Max. 300 bar |
| Material | Black galvanized |
| Connection inlet | Φ6/Φ8 (G1/8) |
| Connection outlet | Φ6/Φ8 (M10x1) |
| Mounting position | Any |
Application
Manufacturing: JINPINLUB JSV divider valves are used for lubrication in such fields as the automation of production lines and mechanical equipment.
Automotive sector: the divider valves JSV are applied for lubrication of diversified mechanical parts along the chains of assembly of automobiles and parts manufacturing processes.
Food and Beverage Industry: JSV divider valves are used in food processing equipment for lubrication in order to maintain the good efficiency of their functioning.
Mining and heavy machinery: In mining equipment and heavy machinery, they are used to lubricate large gears and bearings.
